BIN Source for Firmware for Phantom 4 Advanced and Controller

Help
1

  • What is the latest firmware for the GL300C ver. B Remote Controller

  • What is the latest firmware for the Phantom 4 Advanced

  • I have read that the legacy firmware 1.3.509 is a desired firmware for the Phantom 4 Advanced. However, I have been unable to find a BIN copy of 1.3.509.

  • The firmware for my Phantom 4 Advanced is currently 1.00.0128.

  • I am running Litchi on Google Pixel 9 Pro XL

Any tips on getting my Phantom 4 Advanced updated and linked to Litchi would be appreciated.

2

01.04.03.00

01.00.01.28

That’s a Phantom 4 Pro firmware.

You will need to provide more information and preferably a screenshot.
Do you Force Close DJI GO 4 before running Litchi?

1 Like
3

TriBar -

Thank you for your help

Using the DJI Assistant 2 for Phantom software I was able to verify that the firmware for my Phantom 4 Advanced is 01.00.01.28

I am unable to get my DJI Assistant 2 for Phantom (Windows V2.0.10), or DJI Assistant 2, or DJI Assistant 2 (Consumer Series), or the Android DJI Go 4 App to recognize my GL300C ver. B Remote Controller.

I did find the *.bin file for RC firmware 01.04.03.00 on the DJI website, but it states that it is for a GL300E remote controller, and I have a GL300C.

Prior to a month or so ago, my drone, controller and DJI Go 4 app worked well together.

Currently, my RC is linked to my drone (solid green light on the RC and the drone). I can use the RC to move the camera in a vertical direction, but that is about it. Drone motors will not start using the RC.

Thanks for pointing out that the 1.3.509 firmware is for the Phantom 4 Pro. I had misread an article.

Currently I would like to know which software to use to verify (or refresh) the firmware on my GL300C ver.B Remote Controller.

Or, it might be easier to purchase a GL300E RC. Thoughts…recommendations?

Once again thanks for the help.

Pat

4

Take a look at : Can not link GL300C ver. B to P4P | DJI Phantom Drone Forum

1 Like
5

This tells me you don’t have a software (firmware) problem, but a hardware problem.
The USB-A port on Phantom remote controllers is well known for having so called “dry/cold/cracked solder joints” that need reflowing.

2 Likes
6

This is a real problem with the GL300 remotes. We have two units that refuse to take charge and require a reflow.

1 Like
7

After a couple of attempts I was able to re-link the GL300C ver.B with the Phantom 4 Advanced.

The motors power-up; I have camera movement; But still not able to connect to Litchi.

I have executed a Force Stop on DJI Go 4.

I have made sure that USB Debugging is turned on.

I am using the same cable to connect my Google Pixel 9 PRO XL to the RC that I used with the DJI Go 4 app.

I will check out the reflow.

8

Under magnification I checked the joints on the USB-A outlet. The joints appeared to be okay, but I adjusted the tabs on the USB-A female connector that hold the USB-A male connector firmly in place. And, boom-bada-bing, I had a connection to DJI GO 4. Not the app I wanted to use, but TMRW, (today) I am going to attempt to link to Litchi.

Thanks for the suggestions and help.
